sekundarni kod?!?!
- Turn the xbox 360 on, and wait till the 3 red lights are flashing.
- Press and hold the sync up button (the small white one), while holding that button press the eject button.
- The LEDs will now blink the first number in the code (as described below).
- Release the eject button and press it again.
- The LEDs will now blink the second number of the code.
- Release the eject button and press it again.
- The LEDs will now blink the third number of the code.
- Release the eject button and press it again.
- The LEDs will now blink the forth number of the code.
- Release the eject button and press it again.
- The LEDs will go back to the 3 red flashing lights.
You should be able to determine the difference between the 3 flashing lights and the error code lights by the rate in which they flash.
Here is how you interpret the LEDs to get the code number:
- All four lights flashing - 0
- One light flashing - 1
- Two Lights flashing - 2
- Three lights flashing - 3
pa javi koji cetvorocifreni kod dobijes
evo spiska mogucih kodova i sta koji znaci
0001
power supply problem
0002
Network Interface problem (might be fixed by loosening the x-clamps)
0003
Power problem could be the PSU could be the GPU/CPU, somehow the console isn’t getting clean power from the power supply.
0010
There is a problem with the Southbridge Chip usually dealing with how it connects to the mainboard (cold solder joint/bridged solder joints)
0011CPU over heating – If you are receiving this error after disassembling your console make sure to all 8 of the heatsinc screws are tightened securely to the board/heatsink holes.
0012
GPU over heating -ensure your x-clamps are installed properly.
0013
RAM over heating
0020
GPU Malfunction, similar to error 0102
0021
This can be caused by two completely different things either:
A. DVD Drive Time out – Can be caused by problems with a firmware flash. This is also speculated to sometime be caused by a problem with the southbridge chipset on the motherboard based on how it connects to the DVD drive.
B. GPU error, generally caused by a poor connection to the mainboard (cold solder joints/bridged solder joints) See error 102 for more information
0022
CPU error, generally caused by a poor connection to the mainboard (cold solder joints/bridged solder joints). This can also be triggered by an error with the TSOP.
0023
(not yet known)
0030
Problem with temperature control
0031
could be caused by a short between the heatsink and surrounding capacitors
0032
(not yet known)
0033
(not yet known)
0100
Likely a cold solder join in GPU or Ram chips (see error 0102)
0101
(not yet known)
0102
Error in the “Digital Backbone” (CPU/GPU/RAM), this is usually caused by a cold solder joint between the GPU and the mainboard.
There are two theories to fixing this one deals with the “X” clamps that hold down the chips. The other involves re-heating the chips.
DO NOT attempt either of these if your console is still under warranty. If your console is still under warranty return it to the store where it was purchased or call MS to have it replaced.
0103
GPU Error this is usually caused by bridged solder points where the GPU connects to the mainboard. see error 0102 for more detailed information
0110
Ram error, this is caused by a cold or bridged solder joint on one of the Ram chips.
0200
(not yet known)
0203
over heating GPU possibly due to lack of thermal compound.
1000
Kernel can’t be launched/signature in NAND Flash chip is broken! It could be possible after bad update. http://forums.xbox-scene.com/index.php?sho…p;#entry4156375 This might also be caused by a bad SATA cable.
1001
DVD Drive Error, either incorrect firmware or DVD Time out.
1002
DVD Drive Error, likely a firmware error, drive can eject, read, and write under windows but errors on console, replacing original firmware should fix issue.
1003
Hard Drive Error… It could be a problem with the Hard Drive itself or a problem with the internal connection to the hard drive, Try removing the hard drive and playing without it
1010
Hard Drive Error, Can be caused buy a corrupt or missing eProm. See also E68 above
1011
(not yet known)
1012
(not yet known)
1013
(not yet known) possibly a dashboard update error
1020
(not yet known)
1021
(not yet known)
1022
There is high chance it’s a scaler chip problem (the “ANA” or “HANA” chip near the AV cable connection) it can also be caused by a faulty AV cable so check that first. In some cases it is a problem with the GPU and may be repairable by doing the x-clamp replacement (see error 0102)
1023
DVD drive not connected, connect DVD drive to boot
1030
This error deals with the Ethernet port’s controller chip, a dead chip may not cause the error but removing the Ethernet controller chip does, it may also be caused by other Ethernet related problems.
1031
This error is for power problems with the RAM chips. It might be cause by a short between the heat sink and resistors or by more serious problems with the RAM.
1032
(not yet known)
1033
it could be cpu/gpu related or it could be psu related, not much info is known for sure.
1100
Wrong LDV version in NAND Flash. This is in new dashboard. You have the update but haven’t R3T6 resistor. You can:
-Downgrade to old dashboard, solder back the resistor and then update your xbox
-If you have CPU Key, get current NAND Flash image and fix LDV (just add 1 up to latest kernel). (see error E80)
1444 and up
There is no “4″ in the error codes four lights is a “0″ go back and check your code agai
